10X MANUAL Airplane
5
Model Number...........NER-950S
Type...................10 Channel, PCM-ABC&W
Frequency ..............50/53/72 MHz
Sensitivity
(in microseconds).....5 minimum
Selectivity ..............8 KHz/50dB
Weight (oz) .............1.69
Size (W/L/H) ............ 1.5" x 2.09" x .82"
Receiver Antenna ........39" for all aircraft frequencies.
Model Number ..........NEC-222
Input Voltage ............AC100-120v
Output Current. .........50mAh Tx/120mAh Rx
Charging Time...........15 hours
Type...................1400 mAh Sanyo Extra NiCad
Voltage.................4.8v
Size (W/L/H)............2.64" × .70" × 2.00"
Weight (oz) .............5.4 oz
2.3
Servo Specifications
2.4
Receiver Specifications
2.5
Charger Specifications
2.6
Airborne Battery Packs
Servo NES-8231 Digital
Torque (oz/in)................. 88 oz/in
Speed (S/60°)................. .22
Input Pulse ...................1.5 ms ±600µs
Power Source .................4.8–6.0 volts
Motor .......................Coreless
Weight (oz)...................1.73 oz.
Size (W/L/H) ................. .75" x 1.54" x 1.36"
Component Specification
2
System Name ............J120FS Computer Airplane
System
Transmitter (Main Body) . . NET-J120FS
(RF Module) . . NET-J72P, NET-J50P, NET-J53P
Receiver ................NER-950S
Servos .................DS-8231 Digital
Charger ................NEC-222
Airborne Battery..........1400 mAh Sanyo Extra
®
NiCad
2.1
System Specifications
Model No. ..............NET-J120FS
Encoder ................10 Channel Computer System
RF Module..............50/53/72 MHz
Modulation .............
PCM (S&Z) or PPM
Output Power............Approximately 750 mw
Current Drain............200 mA (70 mA w/DSC)
Power Source............
1.2V x 8 NiCad (9.6V) 1100mAh
Output Pulse (in microseconds) . . . 1000-2000 (1500 neutral)
2.2
Transmitter Specifications
