3-5
3.4
INST
ALLA
TION OF THE POWER CABLE
(CFQ-5436)
This radar equipm
ent comes with
5-m-long cables
with a connector
.
Wiring t
able of the cable CFQ-5436
Color Number
of
wires/diameter(mm)
Cross-sectional
area(mm)
Polarity
Red 50/0.18
1.25
+
Red 50/0.18
1.25
+
Red 50/0.18
1.25
+
Black 50/0.18
1.25
㧙
Black 50/0.18
1.25
㧙
Black 50/0.18
1.25
㧙
CFQ-5436-5 cable
Cable length 5m
29
31
