3-27
S4-6 Set the sensor
Use the gyro.............[OFF]
Use the NMEA ........[ON]
S4-7, 8 Set the baud rate
4800 9600 19200 38400
S4-7 OFF ON OFF ON
S4-8 OFF OFF ON ON
S5: Make settings for S5 according to the type of gyro compass. Refer to the S5 setting table.
S5-1 Make settings according to the type of gyro compass.
Synchro signal ...................... [OFF]
Step signal............................. [ON]
S5-2, 3 Make settings according to the gyration ratio.
360X 180X 90X 36X
S5-2 OFF ON OFF ON
S5-3 OFF OFF ON ON
S5-4 Set the gyration direction.
Normal (clockwise) .............. [OFF]
Reverse (counterclockwise).. [ON]
S5-5 Set the log type.
Pulse signal........................... [OFF]
Synchro signal ...................... [ON]
S5-6 Not in use
S5-7, 8 Set the log ratio.
Pulse/NM (pulse signal)
800 400 200 100
Gyration/NM (synchro signal)
360X 180X 90X 30X
S5-7 OFF ON OFF ON
S5-8 OFF OFF ON ON
TB105 Set the voltage level of step gyro
If the voltage of step gyro is DC24V or less, set the jumper TB105.
side...................................... Normal
side...................................... DC24V or less
To Next Page
