JRC JMA-5204 Installation Manual

3-48
3
(2) JMA-5200MK2 series card slot numbers are assigned as shown below:
Insert the card into the specified slot according to the following table:
Card type Insertion slot No.
JRC card Either one
ERC card Either one
C-Map NT+ detail card Either one
Memory card Either one
Note The Background of C-Map has been built in, don’t insert C-Map NT+ background card.
If the background card is inserted, the system will malfunction.
Slot No.1
Slot No.2
