3-53
(4) Connect inter-unit cable CFQ-5251 to the circular connector of CFQ-5351 attached on the cabinet.
To connect to JMA-5300, cut the inter-unit cable CFQ-5251 at JMA-5300 Processor unit. Then connect
the cable to TB4301 of the processor unit as follows.
Pay attention to the wiring. CFQ-5251 is a cross cable.
Therefore the input wires and output wires are inter-changed between the connectors.
JMA-5200
J9 AUX
JMA-5300 terminal
TB-4301
Remarks
J9-1 TB-4301-6 Radar signal output
J9-2 TB-4301-5 Radar signal output
J9-3 TB-4301- Frame GND
J9-4 TB-4301-10 Radar signal output
J9-5 TB-4301-14 Radar signal output
J9-6 TB-4301-18 Radar signal output
J9-7 TB-4301-9 Radar signal output
J9-8 TB-4301-8 Radar signal input
J9-9 TB-4301-7 Radar signal input
J9-10 TB-4301-12 Radar signal input
J9-11 +12V
J9-12 TB-4301-15 Radar signal input
J9-13 TB-4301-20 Radar signal input
J9-14 TB-4301-11 Radar signal input
2) Setting the JMA-5200MK2
Refer to “4.21 SIMPLIFEDINTER-SWITCH SETTINGS” for initial settings.
