3ļ¼90
JMA-7100 Instruction Manual > 3.BASIC OPERATION > 3.7 USE ROUTE FUNCTION
3.7.8.4 Erasing route data (Erase)
An unnecessary route data file saved on a flash memory card is erased.
Flash memory card (option) is necessary.
Procedures
1) Insert a flash memory card into the card slot.
2) Open the File Operations menu by performing the menu
operation below.
āć
3) Left-click the button.
Contents of the specified memory card (file list) will be displayed.
4) Left-click the button for the desired file name.
Confirmation Window will appear.
5) Left-click the button.
A route data file with the specified file name will be erased.
NOTE:
Once route data files that have been saved on a flash
memory card is erased, the erased data cannot be
resaved. Note that important files should not be erased.
Route
4. File Operation
4. Erase
1. Yes
To Next Page
