JMA-7100 Instruction Manual > 3.BASIC OPERATION > 3.7 USE ROUTE FUNCTION
3ļ¼89
3
3.7.8.3 Loading route data (Load)
Route data is loaded into the radar system from a flash memory card.
Flash memory card (option) is necessary.
Procedures
1) Insert a flash memory card into the card slot.
2) Open the File Operations menu by performing the menu
operation below.
āć
3) Left-click the button.
Contents of the specified memory card (file list) will be displayed.
4) Left-click the button for the desired file name.
Confirmation Window will appear.
5) Left-click the button.
The route data with the specified file name will be loaded.
NOTE:
Once route data has been loaded into the radar system from a
flash memory card, the route data that has been saved in the
radar system is overwritten and erased. Route data that has
been erased cannot be resaved. Note that important route data
should be saved in a flash memory card.
Route
4. File Operation
2. Load
1. Yes
To Next Page
