JMA-7100 Instruction Manual > 9.TROUBLE SHOOTING AND AFTER-SALES SERVICE > 9.1 FAULT FINDING
9ļ¼3
9
TXRX (Trigger) Alarm Scanner: TRIGGER error.. 310
TXRX (Video)
Alarm Scanner: VIDEO error. 309
Wind (Data)
Alarm
Wind direction/velocity: No communication or data error.
118
i. ALR No.: Unique alarm number in ALR sentence and ACK sentence
Table9-3ļ¼ List of Notification
Message Class Description
ALR No.
i
i. ALR No.: Unique alarm number in ALR sentence and ACK sentence
CCRP Changed Note CCRP is automatically changed.
Copying
Note Displayed-image is capturing to file.
POSN Reset
Note Change the latitude and longitude sentence.
Set GYRO
Note Requires setting of true bearing.
TM Reset
Note Resetting TM in a short time.
Tab l e9 - 4ļ¼ List of Target Tracking Alarms and AIS Function Alarms
Message Class Description
ALR No.
i
i. ALR No.: Unique alarm number in ALR sentence and ACK sentence
AIS (Data) Alarm AIS: No communication or communication error. 116
AIS 95% Capacity
Note Over 95% of the maximum number of AIS targets.
AIS ACT 95%
Capacity
Note Over 95% of the maximum number of AIS targets to
be activated.
AIS ACT MAX
Note Maximum number of AIS targets to be activated.
AIS Alarm ***
ii
ii. *** is a 3-digit number which is Local Alarm No in the ALR sentence.
Alarm AIS alarm (Up to 10 alarm messages can be
displayed.).
AIS Max Target
Note Maximum number of AIS targets.
AIS PROC (Data)
Alarm
AIS processing circuit: No communication or
communication error.
328
CPA/TCPA Alarm There is a dangerous target. 301
Lost
Alarm Failure in tracking the target that has been under
tracking.
Failure in receiving AIS target data for a specified
time.
New Target
Alarm Acquisition or activation of a target in the automatic
acquisition / activation zone.
302
REF Target
Alarm Decrease in the reference target accuracy.
Trial
Warning
There is a dangerous target, when trial maneuver is
active.
TT (Boot)
Alarm Target tracking unit start failure. 344
TT (Data)
Alarm The target tracking unit is malfunctioning. 323
TT 95% Capacity
Note Over 95% of the maximum number of targets to be
tracked.
TT MAX Target
Note The maximum number of targets is under acquisition.
Table9-2ļ¼ List of System Error Message
Message Class Description
ALR No.
i
