JMA-7100 Instruction Manual > 9.TROUBLE SHOOTING AND AFTER-SALES SERVICE > 9.1 FAULT FINDING
Table9- 5 ļ¼ List of Route Messages and Warnings
Message Class Description
ALR No.
i
i. ALR No.: Unique alarm number in ALR sentence and ACK sentence
Approach Alarm Approach the route.
Arrival
Alarm Arrive at way point.
Break Off(WPT)
Alarm Out of the way point.
Cross Track Error
Alarm Go off the route.
Table9-6ļ¼ List of Operational Alarm Messages and Warnings
Message Class Description
ALR No.
i
i. ALR No.: Unique alarm number in ALR sentence and ACK sentence
Can't Transmit Note Tried to transmit within 5 second after standby or
when the transmitter-receiver has any trouble.
Card Full
Note Card: Run out of free space.
Copy Failed
Note Card: Copy failure.
Delete Failed
Note Card: Deletion failure.
Format Card
Note Card: Unformatted card.
Format Failed
Note Card: Format failure.
Invalid Card
Note Card: Invalid card.
Invalid Connection
Note The operator set performance monitor to on without
selecting straight.
Invalid Data
Note Tried to enter any data beyond its range.
Invalid Range
Note TM selection due to TM-disabled range (96 nm).
Zooming in a ZOOM-disabled range (0.125 nm).
MAX Point
Note Tried to enter navigation information beyond the
specified.
No Card
Note Card not detected yet.
No Heading Data
Note Target tracking operation or TM selection when
bearing data is invalid.
No Object
Note No object at the cursor-specified position.
No Position Data
Note Mark or line input when the latitude and longitude is
invalid.
Not Allowed
Note General operation error.
Out of Range
Note Out of target acquisition range.
Read Failed
Note Card: Read failure.
Slave Mode
Note Operation of a menu for the scanner unit when the
slave mode is active.
Write Failed
Note Card: Write failure.
