Use for Inflatable Ball/Floating
Equipment/Airbed
1. Choose the right inflator adapter. Secure it to the valve.
2. Turn the unit on, choose from manual or preset mode, and
pump up.
Instructions for the Compressor
Connect the air hose.
Connect the air hose. Make sure the
air hose is screwed all the way to the
compressor.
Connect the air valve.
Push the nozzle onto the valve as far
as possible and push the siphon in the
opposite direction of the hose.
Inflate the tire.
Turn on the compressor by pressing
the ON/OFF button. Press the MODE
button to select the desired pressure.
If the air pressure needs to be
adjusted, you can press the + or -
button.
Press the ON/OFF button to start
pumping. The compressor stops
automatically when the desired
pressure is reached.
