LCD Panel of the Receiver
AF Level: display the strength of audio signal
RF Level: display the strength of radio signal
Antenna Status: the receiver will automatically select an antenna with stronger signal level
Low battery indicator: display the low battery status of its transmitter
Group & Channel: there are four groups, A, B, C, and D with 16 Channels each
3-2 IN64TH
LCD Display
Battery Tray
Set button:
Up button: select the settings of transmitter
Down button: select the settings of transmitter
Power and Mute Switch
LCD Panel of the Handheld Transmitter
Battery status: display battery status
Group & Channel: there are four groups, A, B, C, and D with 16 Channels per
group
f
g
+
-
12
IN
4
6
TH
SET
14 15
16
13
17
