JUKI HZL-NX7 Service Manual

– 6 –
❺
❻
❼
❽
❸
❹
○
Remove setscrews
4
and
5
from the thread tension cover.
Remove the thread tension cover.
○
Remove setscrews
6
to
!0
from the spool cover.
○
Removethebobbinwindingmotorjunctioncablefromthejunctionconnector.
○
Remove the spool cover from the main unit of the machine, paying attention to
thebasetension.
4) Spool cover
Base tension
○
Remove setscrews
❾
to
󱢷
ofthebottomcoverB(onthehandwheelside)to
detachthebottomcoverB.
○
Remove setscrews
󱢸
to
󱢻
ofthebottomcoverA(ontheframeside).Draw
outthebottomcoverAinthedirectionofthearrowwhilepushingupthetipof
the cover.
5) Bottom cover
Junction connector
❾
󱢳
󱢴
󱢵
󱢶
󱢷
󱢺
󱢹
󱢻
󱢸
