Removefree-armlowerbottomcoversetscrews
󱣂
and
󱣃
.Pulloutthebot-
tom cover of the free arm in the direction of the arrow.
7) Bottom cover of the
free arm
8) Upper cover of the
free arm
󱣂󱣂
󱣃󱣃
󱣆󱣆
󱣄󱣄
󱣅󱣅
○
Remove free-arm upper cover setscrews
󱣄
and
󱣅
. Remove setscrew
󱣆
,
the collar and the washer, and pull out the free-arm upper cover in the direc-
tion of the arrow.
Collar
Washer
