JUKI IP-110 Type F User Manual

- 26 -
No Item Description Setting range Indication of function setting
*
8 Number of
rotation of
reverse feed
stitching
Sewing speed of reverse feed stitching
150 to 3,000
(sti/min)
8 1900
9 Thread
trimming
prohibiting
function
This item is not used on the IP-110F.
0/1
9 0
10 Setting of
needle bar stop
position when
the sewing
machine stops.
Position of needle bar is specified when the sewing machine
stops.
0 : Predetermined lowest position
1 : Predetermined highest position
0/1
10 0
11 Operation
conrmation
sound for
operation panel
Operation conrmation sound for operation panel
0 : Operation conrmation sound is not generated
1 : Operation conrmation sound is generated.
0/1
11 1
*
13 Function of
prohibiting start
of the sewing
machine by
bobbin thread
counter
Function of prohibiting start of the sewing machine by bobbin thread counting
0 : When counting is out (-1 or less) Function of prohibiting
start of the sewing machine is not operative.
1 : When counting is out (-1 or less) Function of prohibiting
start of the sewing machine after thread trimming is op-
erative.
2 : When counting is out (-1 or less), the sewing machine
stops once. Function of prohibiting start of the sewing
machine after thread trimming is operative.
0 to 2
13 0
14 Sewing counter Counting function of sewing (number of completion of process)
0 : Sewing counter function is not operative.
1 : Sewing counter function is operative. (Every time thread
trimming is performed)
2 : With the sewing counting switch input function
0 to 2
14 1
15 Thread wiping
function after
thread trimming
Thread wiping operation after thread trimming is specied.
0 : Thread wiping is not carried out after thread trimming
1 : Thread wiping is carried out after thread trimming
0/1
15 1
21 Function of
neutral presser
lifting
Function of lifting presser foot when the pedal is in neutral
position.
0 : Function of neutral automatic presser lifting is not opera-
tive.
1 : Selection of function of neutral presser lifting.
0/1
21 0
22 Needle up/down
correction
switch
changeover
function
Function of the needle up/down correction switch is changed
over.
0 : Needle up/down compensation
1 : One stitch compensation
0/1
22 0
25 Thread trimming
operation after
turning the
handwheel by
han
Thread trimming operation after moving the needle away from
its upper or lower position by turning the handwheel by hand is
specied.
0 : Thread trimming operation is carried out after turning the
handwheel by hand
1 : Thread trimming operation is not carried out after turning
the handwheel by hand
0/1
25 1
29 Initial motion
time of back-
tack
This function sets the suction time of initial motion of back-tack
solenoid.
50 ms to 500 ms
50 to 500
(ms)
29 70
30 Function of
reverse feed
stitching on the
way
Function of reverse feed stitching on the way
0 : Function of reverse stitching on the way is not operative.
1 : Function of reverse feed stitching on the way is operative.
0/1
30 0
31 Number of
stitches of reverse
feed stitching on
the way
Number of stitches of reverse feed stitching on the way.
0 to 19
(Stitches)
31 4
32 Effective
condition of
reverse feed
stitching on the
way when the
sewing machine
is stopping.
Effective condition of reverse feed stitching on the way
0 : Function is not operative when the sewing machine stops.
1 : Function is operative when the sewing machine stops.
0/1
32 0
33 Thread trimming
function by
reverse feed
stitching on the
way
Thread trimming function by reverse feed stitching on the way
0 : Automatic thread trimming function after completion of
reverse feed stitching on the way is not operative.
1 : Automatic thread trimming after completion of reverse
feed stitching on the way is performed.
0/1
33 0
*
35 Number of
rotation at a low
speed
Lowest speed by pedal
(The MAX value differs by machine head.)
150 to MAX
(sti/min)
35 200
*
36 Number of
rotation of
thread trimming
Thread trimming speed
(The MAX value differs by machine head.)
100 to MAX
(sti/min)
36 420
37 Number of
rotation of soft-
start
Sewing speed at the start of sewing (soft-start)
(The MAX value differs by machine head.)
100 to MAX
(sti/min)
37 800
*
Do not change the set values with asterisk (
*
) mark as they are functions for maintenance. If the standard set value set at the
time of delivery is changed, it is in danger of causing the machine to be broken or the performance to be deteriorated.
If it is necessary to change the set value, please purchase the Engineer’s Manual and follow the instructions.
