JUKI IP-110 Type F User Manual

- 27 -
No Item Description Setting range Indication of function setting
38 One-shot speed One-shot speed (The max. value depends on the number of
rotation of the sewing machine head.)
150 to MAX
(sti/min)
38 2500
*
39 Pedal stroke
at the start of
rotation
Position where the sewing machine starts rotating from pedal
neutral position (Pedal stroke)
10 to 50
(0.1 mm)
39 30
*
40 Low speed
section of pedal
Position where the sewing machine starts accelerating from
pedal neutral position (Pedal stroke)
10 to 100
(0.1 mm)
40 60
*
41 Starting position
of lifting presser
foot by pedal
Position where the cloth presser starts lifting from pedal neutral
position (Pedal stroke)
– 60 to –10
(0.1mm)
41 -21
*
42 Starting position
of lowering
presser foot
Starting position of lowering presser foot
Stroke from the neutral position
8 to 50
(0.1 mm)
42 10
*
43 Pedal stroke 2 for
starting thread
trimming
Position 2 where the thread trimming starts from pedal neutral
position (When the function of lifting presser foot by pedal is
provided.) (Pedal stroke)
– 60 to –10
(0.1 mm)
43 -51
*
44 Pedal stroke
for reaching the
maximum number
of rotation
Position where the sewing machine reaches its highest sewing
speed from pedal neutral position (Pedal stroke) 10 to 150
(0.1 mm)
44 150
*
45 Compensation of
neutral point of
the pedal
Compensation value of the pedal sensor
–15 to 15
45 0
47 Auto-lifter
selecting function
Limitation time of waiting for lifting solenoid type auto-lifter
device
10 to 600
(second)
47 60
*
48 Pedal stroke 1 for
starting thread
trimming
Position where thread trimming starts from pedal neutral position
(Standard pedal) (Pedal stroke)
– 60
to – 10
(0.1 mm)
48 -35
49 Lowering time of
presser foot
Lowering time of presser foot after the pedal has been
depressed.
(Start of rotation of the sewing machine is delayed during this
time.)
0
to 250
(10 ms)
49 140
50 Selection of
the pedal
specication
Change the setting according to the pedal specication.
0 : KFL
1 : PFL
0/1
50 1
51 Compensation of
solenoid-on timing
of reverse feed
stitching at the
start of sewing
Compensation of starting the solenoid for reverse feed stitching
when reverse feed stitching at the start of sewing is performed.
– 36 to 36
(10°)
51 -8
52 Compensation of
solenoid-off timing
of reverse feed
stitching at the
start of sewing
Compensation of releasing the solenoid for reverse feed
stitching when reverse feed stitching at the start of sewing is
performed.
– 36 to 36
(10°)
52 10
53 Compensation
of solenoid-off
timing of reverse
feed stitching at
the end of sewing
Compensation of releasing the solenoid for reverse feed
stitching when reverse feed stitching at the end of sewing is
performed.
– 36 to 36
(10°)
53 15
55
Foot lift after
thread trimming
Function of lifting presser foot at the time of (after) thread trimming
0 : Not provided with the function of lifting presser foot after
thread trimming
1 : Provided with the function of lifting presser foot automatically
after thread trimming
0/1
55 1
56
Reverse
revolution to lift
the needle after
thread trimming
Function of reverse revolution to lift the needle at the time of
(after) thread trimming
0 : Not provided with the function of reverse revolution to lift
the needle after thread trimming
1 : Provided with the function of reverse revolution to lift the
needle after thread trimming
0/1
56 0
58
Function
of holding
predetermined
upper/lower
position of the
needle bar
Function of holding predetermined upper/lower position of the needle bar
0 : Not provided with the function of holding predetermined
upper/lower position of the needle bar
1 : Provided with the function of holding predetermined upper/
lower position of the needle bar (holding force is weak.)
2 : Provided with the function of holding predetermined upper/
lower position of the needle bar (holding force is medium.)
3 : Provided with the function of holding predetermined upper/
lower position of the needle bar (holding force is strong.)
0 to 3
58 0
59
Function of Auto/
Manual change-
over of reverse
feed stitching at
the start of sewing
This function can specify the sewing speed of reverse feed
stitching at the start of sewing.
0 : The speed will depend on the manual operation by pedal, etc.
1 : The speed will depend on the specied reverse feed stitching speed (No. 8).
0/1
59 1
60
Function of stop
immediately after
reverse feed
stitching at the
start of sewing
Function at the time of completion of reverse feed stitching at
the start of sewing
0 : Not provided with the function of temporary stop of the
sewing machine at the time of completion of reverse feed
stitching at the start of sewing
1 : Provided with the function of temporary stop of the sew-
ing machine at the time of completion of reverse feed
stitching at the start of sewing.
0/1
60 0
*
Do not change the set values with asterisk (
*
) mark as they are functions for maintenance. If the standard set value set at the
time of delivery is changed, it is in danger of causing the machine to be broken or the performance to be deteriorated.
If it is necessary to change the set value, please purchase the Engineer’s Manual and follow the instructions.
