- 4 -
3. Adjusting the Transport Height and Leveling the Machine
Cover RBR
Cover RBC
Level vial
Base bar B
Base bar R
Base bar F
Caster
Cover FB
Adjuster
r
q
w
e
Cover RBL
Figure 3.2 (Viewing from the bottom of unit.)
Figure 3.1 (Viewing from the top of unit.)
