JUKI MO-6000S series - Adjusting the Height and Clearance of the Needle Guard; For 1-Needle or 2-Needle Overlock Machine; For Safely Stitch Machine

−22 −
Standard Adjustment
(10) Adjusting the height and clearance of the needle guard
1) For 1-needle or 2-needle overlock machine
Make needle guard A lightly come in contact with the top end of needle (bend needle by 0 to 0.05
mm) when the blade point of the lower looper reaches the needle center.
The clearance between needle guard B and the needle is 0.1 mm when the needle is at the lowest
point of its stroke.
The height of needle guard B is 1 mm from the throat plate bottom surface.
2) For safely stitch machine
The safely stitch machine has four needle guards, A, B, C and D. The needle guards A and B are
positioned in the same manner as those for the overlock machine.
The needle guard C should be positioned 5 mm below the throat plate bottom surface.
Needle guard A
(Traveling needle guard)
Light
touch
the
needle
guard
A
Needle guard B
Throat plate
1 mm
0.1 mm
B
B
C
D
Throat plate
5 mm
Lightly touches
0.1mm
