−67 −
B
D
J
K
I
H
F
E
C
A
G
B
D
J
K
I
H
F
E
C
A
G
D
K
H
C
G
MO-6904G (J), 6914G (J), 6916G (J)
MO-6905G
MO-6903G
(Unit : mm)
(Caution) The upper looper thread-take-up (right)
and the looper thread take-up (left) shall
be positioned at the extreme right point
of the upper looper.
Position MO-6904G(J)-0F6-700 MO-6914G(J)-CH6-700 MO-6916G(J)-F 6-700 MO-6905G-0M6-7 0 MO-6903G-0N6-3D1
A70 ,,65 -
B22 ,,20 -
C48 ,,46 52
D18 ,,,,
E43 ,,22 -
F22 ,,18 -
G11 ,,16 13
H27 ,,26 31
I23 ,,20 -
J18 ,,10 -
K17 ,,,27
