JUKI SC-510 Engineer's Manual

−16 −
38
39
40
One-shot
speed
Pedal stroke at
the start of
rotation
Low speed
section of
pedal
One-shot speed (The max. value depends on the number of rotation
of the sewing machine head.)
Position where the sewing machine starts rotating from pedal neutral
position (Pedal stroke)
Position where the sewing machine starts accelerating from pedal
neutral position (Pedal stroke)
150 to MAX
(rpm)
10 to 50
(0.1 mm)
10 to 100
(0.1 mm)
*
Item
No.
Setting
range
Description
Ref.
page
24
24
24
25
25
25
25
26
26
26
26
27
20
27
Indication of
function setting
Suction time of
the first start of
the back
solenoid
Function of
reverse feed
stitching on the
way
Number of
stitches of
reverse feed
stitching on the
way
Effective
condition of
reverse feed
stitching on the
way when the
sewing
machine is
stopping.
Thread
trimming
function by
reverse feed
stitching on the
way
Number of
rotation at a
low speed
Number of
rotation of
thread
trimming
Number of
29
30
31
32
33
35
36
37
This function sets the suction motion time of the back-tack solenoid.
50 ms to 500 ms
Function of reverse feed stitching on the way
0 : Function of reverse stitching on the way is not operative.
1 : Function of reverse feed stitching on the way is operative.
Number of stitches of reverse feed stitching on the way.
Effective condition of reverse feed stitching on the way
0 : Function is not operative when the sewing machine stops.
1 : Function is operative when the sewing machine stops.
Thread trimming function by reverse feed stitching on the way
0 : Automatic thread trimming function after completion of reverse
feed stitching on the way is not operative.
1 : Automatic thread trimming after completion of reverse feed
stitching on the way is performed.
Lowest speed by pedal
20 Number of rotation at the time of thread trimming is set.
(This setting is prior even when number of rotation is lower than the
lowest speed by pedal of No. 35.)
Sewing speed at the start of sewing (soft-start)(The max. value
depends on the number of rotation of the sewing machine head.)
50 to 500
(ms)
0/1
0 to 19
(Stitches)
0/1
0/1
150 to 250
(rpm)
100 to 250
5 (rpm)
100 to MAX
(rpm)
29
250
40
60
39
30
38
2500
36
100
35
200
33
0
32
0
31
4
30
0
22
24
Function of
changeover of
compensating
switch on the
operation
panel function
Function of
input of
presser for
standing work
Function of needle up/down compensating switch on the operation
panel can be changed.
0 : Needle up/down compensation
1 : One stitch compensation
Motion of switch for presser of pedal for standing work is set.
0 : Normal presser motion (FLsw)
1 : Alternate motion of input of normal presser
2 : Alternate vertical switch (DLsw) function
3 : Alternate motion of alternate vertical switch (DLsw)
4 : Level input wrapper control and presser synchronizing control
5 : Level input wrapper control
6 : Alternate input wrapper control
0/1
0 to 6
25
1
22
0
21
0
20
10
19
359
Reversing
brake start
angle
Alternate
vertical amount
output delay
time
Function of
neutral presser
lifting
19
20
21
Stop brake start angle of reverse revolution to lift needle input (Rsw)
is set.
0 : UP detection missed
Output start delay time of alternate presser output signal of LH series
is set.
Function of lifting presser foot when the pedal is in neutral position.
0 : Function of neutral automatic presser lifting is not operative.
1 : Selection of function of neutral presser lifting.
0 to 359
(degree)
0 to 500
(ms)
0/1
24
2
37
800
* Do not change the set values with asterisk (*) mark as they are functions for maintenance. If the standard set value set at the time
of delivery is changed, it is in danger of causing the machine to be broken or the performance to be deteriorated.
(Descriptions of setting in this list are the standard values at the time of delivery.)
However, contents of function setting are subject to change for improvement of function and performance without notice.
25
Thread
trimming
motion
condition
This function sets the thread trimming motion after DOWN position
has been off by turning handwheel by hand.
0 : Thread trimming after turning handwheel by hand is permitted.
1 : Thread trimming after turning handwheel by hand is prohibited.
0/1
Start
level
S
S
U
U
U
U
U
U
U
U
U
U
S
U
U
U
U
(Start level ; U : User's mode, S : Service mode)
