JUKI SC-510 Engineer's Manual

−21 −
8 Selection of the optional input/output function (Function setting No. 12)
12
OPT _
900
_End
in__
ouT_
***901
908
***911
918
12
OPT _
900
in__
noP901
TSW901
[\
L4
L4901
H4
[\
noP902
900
in
End
1
2
4
3
1. Select function No. 12 with the operating procedures described in the item
of how to change over the function setting mode (1) to (4).
Select the items of "End", "in" and "ouT" with keys 3 and 4.
[When "in" is selected]
The port Nos. are displayed in the left 3 digits. Designate the input port with
key 1 or 2. Designate the function of input port with key 3 or 4.
The function code and the abbreviation are alternately displayed in the 4-digit
LED.(For the relation between signal input No. and connector pin array, refer
to the separate list.)
[When "ouT" is selected]
The port Nos. are displayed in the left 3 digits. Designate the output port with
key 1 or 2. Designate the function of output port with key 3 or 4.
The function code and the abbreviation are alternately displayed in the 4-digit
LED. (For the relation between signal input No. and connector pin array, refer
to the separate list.)
(Caution) Note that the voltage used in output function should not exceed the voltage set with W1
and W2.
* Example) Setting the thread trimming function to the optional input port 1
1. Select function No. 12 with the operating procedures described in the item
of how to change over the function setting mode (1) to (4).
2. Select the item of "in" with keys 3 and 4.
3. Select the port of 901 with key 2.
4. Select the thread trimming function, "TSW" with keys 3 and 4.
5. Determine the thread trimming function, "TSW" with key 2.
6. Set ACTIVE of the signal with keys 3 and 4.
Set the display to "L" when the signal is "Low" and performing thread
trimming, and set the display to "H" when the signal is "High" and performing
thread trimming.
7. Determine the aforementioned function with key 2.
8. Finish the optional input with key 2.
9. Select the item of "End" with keys 3 and 4 to return to the function setting
mode.
* For the other optional function, it is possible to program simple input/output sequence control.
Operation keys array
Optional input
1 to 8 are
displayed.
Optional output
1 to 8 are
displayed.
Lighting alternately
<?
<?
･･･
