Julabo F12 - Part Description

Spare parts list F12
11
Spare parts list F12: Print date 05.10.06 7.920.2212
POS.
NO.
PART DESCRIPTION ORDER-NO. FROM
DATE
FROM
BARCOD
E NO.
Wiring diagram F12 230V 50 Hz Euro 1.590.0228-V0
Wiring diagram F12 115V 60Hz 1.590.0228-V1
Cooling control board circuit diagram 7.537.3020 0S0
Refrigerant circuit diagram F12 1.650.0033 05.10.06
100 Mains switch complete 230 V. 7.901.0073
101 Mains switch complete 115 V. 7.901.0565
110 Set of rubber feet 7.901.0078
120 Condenser F12 7.901.0602
130 Protection for metal edge (2x 17 cm) 7.901.0603
140 Catch lock 7.901.0108
150 Drain tap 7.901.0394
160 Bath lid complete F12 7.901.0053
170 Handle for bath lid 7.901.0058
180 Cable support 7.901.0059
190 Fine fuses T10,0 A - D5x20 mm 7.901.0604
191 Circuit breaker 15 A / 250 VDC, 1 piece 7.901.0566
200 Panel socket complete Euro. 7.901.0605
201 Panel socket complete USA. 7.901.0606
210 Mains power cable complete Euro 7.901.0061
211 Mains power cable complete USA 7.901.0062
212 Mains power cable complete Euro
(with screw cable gland M15x1.5 mm)
7.901.1080 07.2004
220 Cooling control board complete 230 V 7.901.0607
221 Cooling control board complete 115 V 7.901.0608
230 Axial ventilator complete 230 V 50 Hz 7.901.0609
231 Axial ventilator complete 115 V 50-60 Hz 7.901.0610
240 Compressor complete 230V/50Hz F12 (Elektrolux) 7.901.0611
241 Compressor complete 115V/60Hz F12 (Elektrolux) 7.901.0612
242 Compressor complete 115V/60Hz F12 USA
(Elektrolux)
7.901.0613
243 Compressor complete 230V/60Hz F12 Korea 7.901.1079 07.2004
