JUMO diraTRON 108 Interface Description

4 Modbus addresses
26
4.2 Addresses
The following tables contain configuration parameters, commands, and process values for the device in-
cluding its address, data type, and type of access.
In principle, the specifications apply to devices of type 70211x (compact controllers) and type 70151x
(digital indicators). Exceptions are indicated in the relevant sections.
4.2.1 Configuration data
Analog input
Flags
Timer
Limit value monitoring functions
Address Data type Access Designation
Hex. Dec.
0x17C0 6080 FLOAT R/W Measured value offset
0x17C2 6082 FLOAT R/W Filter time constant
Address Data type Access Designation
Hex. Dec.
0x1B00 6912 FLOAT R/W 1. analog flag
0x1B0B 6923 FLOAT R/W 2. analog flag
0x1B16 6934 BOOL16 R/W 1. digital flag
0x1B17 6935 BOOL16 R/W 2. digital flag
Address Data type Access Designation
Hex. Dec.
0x1B24 6948 UINT32 R/W Timer time (timer value)
Address Data type Access Designation
Hex. Dec.
Limit value monitoring 1
0x1B7B 7035 FLOAT R/W Limit value
0x1B7D 7037 FLOAT R/W Limit value 2
Limit value monitoring 2
0x1BCB 7115 FLOAT R/W Limit value
0x1BCD 7117 FLOAT R/W Limit value 2
Limit value monitoring 3
0x1C1B 7195 FLOAT R/W Limit value
0x1C1D 7197 FLOAT R/W Limit value 2
Limit value monitoring 4
0x1C6B 7275 FLOAT R/W Limit value
0x1C6D 7277 FLOAT R/W Limit value 2
