JUMO diraTRON 108 Interface Description

31
4 Modbus addresses
Setpoint values (only for type 70211x)
Ramp (only for type 70211x)
4.2.2 Commands
External analog inputs (via an interface)
External digital inputs (via an interface)
0x20A0 8352 UINT32 R/W Duration
0x20A2 8354 BIT16 R/W Operating contacts (see section 1)
Section 24
0x20A3 8355 FLOAT R/W Setpoint value (see section 1)
0x20A5 8357 FLOAT R/W (reserved)
0x20A7 8359 UINT32 R/W Duration
0x20A9 8361 BIT16 R/W Operating contacts (see section 1)
Address Data type Access Designation
Hex. Dec.
Address Data type Access Designation
Hex. Dec.
0x2114 8468 FLOAT R/W Setpoint value 1
0x212A 8490 FLOAT R/W Setpoint value 2
0x2140 8512 FLOAT R/W Setpoint value 3
0x2156 8534 FLOAT R/W Setpoint value 4
Address Data type Access Designation
Hex. Dec.
0x2201 8705 FLOAT R/W Positive gradient
0x2203 8707 FLOAT R/W Negative gradient
0x2205 8709 FLOAT R/W Tolerance band
Address Data type Access Designation
Hex. Dec.
External analog input 1
0x3700 14080 FLOAT R/W Value of the analog input
External analog input 2
0x370A 14090 FLOAT R/W Value of the analog input
Address Data type Access Designation
Hex. Dec.
External digital input 1
0x37A1 14241 BOOL16 R/W Value of the digital input
External digital input 2
0x37AB 14251 BOOL16 R/W Value of the digital input
