JUMO diraTRON 108 Interface Description

4 Modbus addresses
34
Digital signals
In this section, different digital signals are listed under consecutive addresses so that they can be ex-
tracted using a read operation.
Some of these signals are also listed in the section of the respective function – under a different address.
0x704C 28748 FLOAT R/O 5. ST analog output X X
0x704E 28750 FLOAT R/O 6. ST analog output X X
0x7050 28752 FLOAT R/O Analog output X X
0x7052 28754 FLOAT R/O Service counter X X
0x7054 28756 FLOAT R/O Operating time X X
a
X = Process value exists; --- = Process value does not exist (undefined value)
Address Data type Access Designation Type
a
Hex. Dec. 70211x 70151x
Address Data type Access Designation Type
a
Hex. Dec. 70211x 70151x
0x6D50 27984 BIT16 R/O Limit value monitoring functions X X
0000 0000 0000 0001 = Limit value monitoring 1 active
0000 0000 0000 0010 = Limit value monitoring 2 active
0000 0000 0000 0100 = Limit value monitoring 3 active
0000 0000 0000 1000 = Limit value monitoring 4 active
0x6D51 27985 BIT16 R/O Timer X X
0000 0000 0000 0001 = Timer output active
0000 0000 0000 0010 = End signal active
0000 0000 0000 0100 = Tolerance band signal active
0000 0000 0000 1000 = Stop signal active
0x6D52 27986 BIT16 R/O Digital outputs X X
0000 0000 0000 0001 = Digital output 1 active
0000 0000 0000 0010 = Digital output 2 active
0000 0000 0000 0100 = Digital output 3 active
0000 0000 0000 1000 = Digital output 4 active
0000 0000 0001 0000 = Digital output 5 active
0000 0000 0010 0000 = Digital output 6 active
0000 0000 0100 0000 = Digital output 7 active
0x6D53 27987 BIT16 R/O Digital control signals X X
0000 0000 0000 0001 = Control signal 1 active
0000 0000 0000 0010 = Control signal 2 active
0000 0000 0000 0100 = Control signal 3 active
0000 0000 0000 1000 = Control signal 4 active
0x6D54 27988 BIT16 R/O Digital inputs X X
0000 0000 0000 0001 = Digital input 1 active
0000 0000 0000 0010 = Digital input 2 active
0x6D55 27989 BIT16 R/O External digital inputs X X
0000 0000 0000 0001 = Ext. digital input 1 active
0000 0000 0000 0010 = Ext. digital input 2 active
