3 Identifying the device version
10
01 10 % Only with TR and TW
(6) Capillary length
0 None
1000 1,000 mm
2000 2,000 mm
3000 3,000 mm
4000 4,000 mm
5000 5,000 mm
(7) Capillary material
20 CrNi (stainless steel)
40 Cu (copper)
(8) Process connection
10 Plain cylindrical probe
20 Screw-in protection tube
(9) Thread of process connection
00 None
13 G 1/2
(10) Process connection material
00 None
20 CrNi (stainless steel)
40 CuZn (brass)
(11) Insertion length
000 None
100 100 mm
120 120 mm
150 150 mm
200 200 mm
300 300 mm
(12) Protection tube diameter
00 None
10 10 mm
88mm
(13) Probe diameter
66mm
88mm
(14) Extra codes
000 None
025 Central mounting M10 × 1, metall
574 Microswitch with N/C contact, restart lock, and additional signal contact (only for TB and STB)
699 Screw connection up to 2.5 mm²
702 Snap-action contact, gold-plated
704 Switching head mounting with 2 M4 screws, spaced 28 mm
705 Switching head mounting with 2 M3 screws, spaced 33 mm
707 Temperature compensation
710 Central mounting M10 × 1, standard
