JUMO EM Series User Manual

7 Technical data
30
7.2 Control ranges and temperature probes
For STB and STW (STB) – liquid-filled
For STB and STW (STB) – gas-filled
When the switching points are permanently factory-set, the deactivation value must be specified in ad-
dition to the control range (e.g. control range 80 to 100 °C, permanently set to 95 °C).
7.3 Capillary and temperature probe
Setting
range
Scale
range
Max. probe
temperature
Max.
switching head
temperature
Max. capillary
length
Limit
value
tolerance
Probe length "L",
probe Ø "d"
in mm
°C °∠ °C °C in mm K Ø 6 (Standard) Ø 8
75 to 100 78 125 80 5000 +0
-7
84 63
85 to 110 78 135
120 to 150 77 173 +0
-9
80 57
160 to 200 79 230 +0
-12
64 49
210 to 250 71 288 +0
-13
61 47
250 to 300 79 345 +0
-16
55 -
Setting
range
Scale
range
Max. probe
temperature
Max.
switching head
temperature
Max. capillary
length
Limit
value
tolerance
Probe length "L",
probe Ø "d"
in mm
°C °∠ °C °C in mm K Ø 6 (Standard) Ø 8
300 to 400 70 460 80 3000 +0
-23
148 92
350 to 500 72 575 +0
-29
127 81
Type Scale limit value Capillary Probe
EM-... Up to 200 °C Copper (Cu)
Ø1.5mm
Material no. Cu-DHP
Copper (Cu)
Material no. Cu-DHP
Hard soldered
Up to 350 °C Copper (Cu)
Ø1.5mm
Material no. Cu-DHP
Stainless steel (CrNi)
Material no. 1.4571
Hard soldered
Up to 500 °C Stainless steel (CrNi)
Ø1.5mm
Stainless steel (CrNi)
Material no. 1.4571
Welded
Up to 350 °C Stainless steel (CrNi)
Ø1.5mm
Stainless steel (CrNi)
Material no. 1.4571
Welded (available at extra cost)
Capillary length Standard 1,000 mm, max. 5,000 mm
Min. bending radius of capillary 5 mm

JUMO EM Series Specifications

General

Housing Material	Plastic
Temperature Range	-50 to 400°C
Display	LCD
Power Supply	24 V AC/DC
Output	Relay, Analog
Input	Analog
Control Mode	PID, On/Off
