JUMO EM Series User Manual

7 Technical data
32
7.5 Operating data
Switching differential in %
of control range/limit value range
Measuring system
Liquid-filled Gas-filled
Nominal
value
Possible actual
value
Nominal
value
Possible actual
value
Switching function
TR, TW 2.5 Approx. 2.5 to 3.5 5 Approx. 5 to 11 Standard
5 Approx. 5 to 6 6 Approx. 6 to 14 Upon request
7 Approx. 7 to 8 10 Approx. 10 to 16 Upon request
1 Approx. 1 to 2 3 Approx. 2.5 to 4 Extra cost
STW (STB) 5 Approx. 5 to 7 6 Approx. 6 to 16 Standard
Sequence contact gap on multi-
pole versions
Switching
differential
Sequence contact gap relative to
scale range
Switching point accuracy
of the sequence contact
gaps from the scale range
Minimum Maximum
1 % 1 % According to control
range table
≤1%
2.5 % 1 % ≤ 1 %
3%, 5% 2% ≤1%
6%, 7%, 10% 3% ≤1%
The sequence contact gap can be specified in °C in relation to the setpoint of
contact I.
(The contact track no. is stamped on the back of the housing par.)
Prefix - = switching before reaching the setpoint value
Prefix + = switching after reaching the setupoint value
For the synchrozized version, specify "0" as the sequence contact gap.
Switching point accuracy in %
of control range/limit value range
Switching differential In the upper third of the scale or
limit value
Liquid-filled Gas-filled
Switching function
TR 1%, 2.5% - ±1.5%
5% 3%, 5% ±3%
7% 6%, 10% ±4%
TW 1%, 2.5% - ±1.5%
5% 3%, 5% ±3%
7% 6%, 10% ±4%
TB - - +0 %
-5 %
STW (STB) See table for control ranges and probes

JUMO EM Series Specifications

General

Housing Material	Plastic
Temperature Range	-50 to 400°C
Display	LCD
Power Supply	24 V AC/DC
Output	Relay, Analog
Input	Analog
Control Mode	PID, On/Off
