JUNCTEK
JDS8000 Series User’s Manual
When the input box is open, it is the number key 4.
【
VCO
】
Key
For quick switching between voltage control mode interface and main
interface.
Press the
【
VCO
】
key to enter the voltage control frequency interface, press
the
【
Func
】
soft key and then use the corresponding soft key to switch
between the functions of frequency control, amplitude control and duty
control. When the input box is open, it is the number key 5.
【
MEAS
】
Key
For quick switching between measurement mode interface and main
interface.
Press the
【
MEAS
】
key, and then press the
【
Cnt
】
and
【
Meas
】
soft
keys in the measurement mode interface to switch between the
measurement function and the counter function. When the input box is
open, it is the number key 6.
(8) Function softkeys
Corresponding to the menu on the right side of its screen, pressing this soft
key activates the corresponding menu.
When the input box is turned on, the menu on the right side of the screen
corresponds to 0, ., +/-, confirm, and exit.
(9) LCD
The 2.8-inch TFT color LCD display shows the menu and parameter settings of
the current function.
(10) Function softkeys
【
MEM
】
Key
Press the
【
MEM
】
button, the message box will display and recall M00,
and at the same time enter the input box function, you can press the
number key + OK button to recall the parameters; press the
【
SHIFT
】
+
【
MEM
】
buttons, the information box display save M00, you can press the
number key + OK key to save the parameters.
【
InBox
】
Key
Press the
【
InBox
】
button, and the corresponding pop-up window will
appear on the screen. For example, when the cursor is in the frequency
setting, press the
【
InBox
】
button, the pop-up window will jump out for
inputting the frequency value. At this time, the rotating the knob can select
the corresponding unit, and the input box is turned on. At the same time,
the left side of the menu soft key also corresponds to 0, ., +/-, confirm, and
exit.
