3.Specifications
Frequency Characteristic
Model
JDS8060
JDS8080
Sine waveform frequency range
1nHz~60MHz
1nHz~80MHz
Square waveform frequency
range
1nHz~15MHz
1nHz~15MHz
Triangle waveform frequency
range
1nHz~15MHz
1nHz~15MHz
Pulse waveform frequency range
1nHz~10MHz
1nHz~10MHz
TTL digital waveform frequency
range
1nHz~6MHz
1nHz~6MHz
Arbitrary waveform frequency
range
1nHz~6MHz
1nHz~6MHz
Pulse width adjustment range
20nS~4S
20nS~4S
Rise time
≤20ns
≤10ns
Fall time
≤20ns
≤10ns
Frequency minimum resolution
1nHz
（
0.000000001Hz
）
Frequency accuracy
±5ppm 0 to 50℃
Frequency stability
±3ppm per 1 year
Waveform Characteristics
Waveform type
Sine wave, square wave, triangle wave, pulse
wave (duty cycle adjustable, pulse width and cycle
time precisely adjustable), ramp, CMOS wave, DC
level (setting DC amplitude by adjusting bias),
partial sine wave, half wave, full wave, positive
ladder wave, anti ladder wave, positive ladder
wave, anti ladder wave, noise wave, exponential
rise, exponential drop, logarithmic rise, logarithmic
drop, cinker pulse, multi audio wave Lorentz pulse
and 99 user-defined waveforms.
Wave length
8192 points/channel
Sampling rate
275MSa/S
Waveform vertical resolution
14 bits
Harmonic suppression
≥45dBc(<1MHz); ≥40dBc(1MHz~20MHz)
Total harmonic distortion
<1%(20Hz~20kHz,0dBm)
Square wave and pulse wave
overshoot
≤5%
Duty cycle adjustment range
0.01%~99.99%
Sawtooth waveform linearity
≥98%
（
0.01Hz-10kHz
）
Output Characteristics
Amplitude range of the sine
waveform
Frequency＜1MHz
1MHz≤Frequency＜11MHz
2mVpp~25Vpp
2mVpp~20Vpp
