JDS8000 Series User’s Manual
35
External synchronization: Soft keys
【
ON
】
and
【
OFF
】
can be used to turn
on and off external synchronization.
Restoring factory settings: Press the soft key
【
RUN
】
, select
【
RUN
】
to
restore the factory settings, and “Running...” is displayed in the information box,
and the progress bar is full, which means the operation is successful.
Press soft key
【
PgDn
】
to enter the third page of system settings.
Auto Power On: The soft keys
【
ON
】
and
【
OFF
】
can be used to turn on and
off the automatic power on. After the automatic power-on function is enabled,
the instrument defaults to power-on output.
CH1 amplitude fine-adjusting: When there is a slight difference between the
output amplitude of the CH1 channel waveform and the amplitude you
measure, you can change the value of the CH1 amplitude fine-adjusting and
perform online calibration to obtain an accurate amplitude. The default CH1
amplitude trim value is 50.
CH2 amplitude fine-adjusting: When the output amplitude of CH2 channel
waveform is slightly different from the amplitude you measure, you can change
the value of CH2 amplitude fine-adjusting and perform online calibration to
obtain accurate amplitude. The default CH2 amplitude trim value is 50.
Help information: Rotate the knob or scan the QR code with your mobile phone
to view related help information.
8.Voltage control mode parameter settings
Communication protocol and software instruction link:
http://68.168.132.244/JDS8000/Setup_EN.zip
(1) Install software
 Step 1: Click the button
【
JDS8000 Setup
】
to install the application, click
the
【
NEXT
】
key*4→
【
Install
】
key*1→
【
Finish
】
key*1 to complete the
installation. The application installation interface is shown in Figure 3-8-1 to
Figure 3-8-6 below.
