74
Sticking
I)
Material to be attached (magnetic hol-
der, self-adhering on the back side) con-
forming to EN 14604: 2005/AC: 2008
Attention:
If only this self-adhesive fastener is
used, it installs the device in a very
maintenance-friendly and secure mag-
netic connection with the installation
base, thus enabling the device to be
removed by gently pulling out the ma-
gnetic holder vertically (for inspection,
maintenance, cleaning).
Use only the provided adhesive for sti-
cking the device. The place of installati-
on must be rm, dry and free of grease,
dust and loose sections etc.
As shown in Illus. 2, remove the infor-
mation sticker and then the protecti-
ve lm on the adhesive stuck on the
magnet and press the correct surface
of the magnetic holder for about 10
seconds on the place of installation.
You can then position the device on
the magnetic holder (Illus. 1 point b).
If required, the device can be gently pul-
led up vertically to remove it from the
magnetic holder.
The device will nally adhere after
about 72 hours.
II)
Additional (optional) fastening mate-
rial (thin, double-sided sticking lm)
according to vfdb 14/01 (Q) and EN
14604:2005/AC:2008.
Attention:
Using this additional material will give
you very rm adhesion and therefo-
re a long-term xture of the device to
the fastener mentioned in I) (magnetic
en
