87
03.13 EN
2.4 Display
Item Function
111 – Remaining time in the format hours : minutes
– Remaining charge time (o)
112 Time display (hours : minutes)
113 Operating program display
– Displays the travel program in use
114 Error display:
– If an error (Err) or a warning (Inf) occurs, the error or info
code is displayed.
– If several errors occur they are displayed alternately at
1.5 second intervals. A warning sounds.
115 Battery capacity display
– Battery discharge status
– Charge status display for on-board charger (o)
116 Hourmeter display
117 Travel direction, speed and wheel position display
– Indicates the pre-selected travel direction (forward or
reverse) or the position of the steered wheels.
– Flashing direction arrow = no travel direction selected
km/h
pm
am
100 %
m kg eff code err
inch lbs
111 112
113
117
116
115
114
