LMR400 (5-m Segment) Cable Specicaons
Electrical Characteriscs
Impedance 50 Ω
Frequency DC-3GHz
Voltage Rang 335 Vrms
Dielectric Withstanding Voltage > 1000 V
Insulaon Resistance > 5000 MΩ
Cabling Guidelines
Follow these guidelines when you install cables:
• Ensure that the GNSS dongle can track the satellites and can acquire a lock.
• Examine the cable end points and connectors for any bends or damage.
• Check the electrical connuity of the cable for both inner and outer conductors.
• Check for any electrical short in cables.
• Inspect the cable outer sheath for any damage.
10
