Juniper CTP2000 Series Hardware Guide

Table 11: CTP2000 4WE&M RTM Pinouts–Connector A (continued)
Connector A
PinSignalSignalPin
27Port 0 T1Port 0 R12
28Port 0 EPort 0 SG3
29Port 0 MPort 0 SB4
30Port 1 TPort 1 R5
31Port 1 T1Port 2 R16
32Port 1 EPort 2 SG7
33Port 1 MPort 2 SB8
34Port 2 TPort 2 R9
35Port 2 T1Port 2 R110
36Port 2 EPort 2 SG11
37Port 2MPort 2 SB12
38Port 3 TPort 3 R13
39Port 3 T1Port 3 R114
40Port 3 EPort 3 SG15
41Port 3 MPort 3 SB16
50GNDGND25
CTP2000 4WE&M Connector B Pinouts
See Table 12 on page 47 for connector B pinout information. See“CTP2000 4WE&M Interface Module”
on page 14 for signal definitions.
