Juniper CTP2000 Series Hardware Guide

CTP2000 FXS and FXO Interface Module Cables and Pinouts | 48
CTP2000 Series Console Cable Pinouts | 63
CTP2000 FXS and FXO Interface Module Cables and Pinouts
IN THIS SECTION
Required Cables | 48
RTM Pinout Locations | 48
FXS Connector Pinouts | 49
FXO Connector Pinouts | 50
Required Cables
The CTP2000 2W-FXS and 2W-FX0 interface modules require the use of double-shielded cables (copper
braid plus aluminum mylar foil) to ensure EMI Compliance.
RTM Pinout Locations
Figure 29 on page 49 shows the pinout locations for both the CTP2000 2W-FXS and 2W-FXO interface
modules.
48
