Juniper Day One Plus SRX380 User Manual

6. While you’re holding the SRX380 in place, have a second person insert and tighten the rack mount screws to secure
the mounting brackets to the rack rails. Make sure they tighten the screws in the two bottom holes first and then
tighten the screws in the two top holes.
g100947
7. Continue holding the SRX380 in place and have the second person slide the mounting blades into the channel of the
mounting rails.
g100948
8. Screw the mounting blades to the rack using the rack mount screws.
9. Check that the mounting brackets on each side of the rack are level.
Power On
Now that you’ve installed your SRX380 in the rack, you’re ready to connect it to power.
4

Juniper Day One Plus SRX380 Specifications

General

Model	SRX380
Memory	8 GB
Rack Height	1U
Application Identification Throughput	10 Gbps
Form Factor	1U
Storage	16 GB
Power Supply	Dual redundant AC power supplies
