JUNOSe 7.2.x Policy Management Configuration Guide
114 ! CAM Hardware Classifiers
The format in the classifier entry combinations in Ta b l e 1 9 is based on the
conventions for CLI commands, except that the pipe symbol ( | ) represents a
choice of one or both options to the left and right of the pipe symbol.
Table 19: Size Limit of Combined IPv6 Classifiers
IPv6 Classifier Entry Combination Size Limit (Bits) Rule
Color or TCP flags or both 8 When you specify the color and/or TCP flags
classifiers, 8 bits are added to the total classifier
entry size.
Destination address (first word) 32 –
Destination address (second word) 32 –
Destination address (third word) 32 –
Destination address (fourth word) 32 –
Destination address route class 8 –
[ Destination port ] and
[ [ ICMPv6 type ] | [ ICMPv6 code or nil ] ]
16 When you specify the destination port
classifier, 16 bits are added to the total classifier
entry size. If you also specify the ICMPv6 type
and ICMPv6 code classifiers, no additional bits
are added to the total classifier entry size.
[ No source port ] and [ no destination port ] and
[ [ ICMPv6 type ] | [ ICMPv6 code ] ]
16 When you do not specify the source port and
destination port classifiers, and you have
already specified one or more of the ICMPv6
Type and ICMPv6 code classifiers, 16 bits are
added to the total classifier entry size.
The ICMPv6 type and ICMPv6 code classifiers
require 16 bits even if you have not specified
the source port and destination port classifiers.
Protocol 8 –
Source address (first word) 32 –
Source address (second word) 32 –
Source address (third word) 32 –
Source address (fourth word) 32 –
Source address route class 8 –
[ source port ] and
[ [ ICMPv6 type ] | [ ICMPv6 code ] ]
16 When you specify the source port classifier, 16
bits are added to the total classifier entry size. If
you also specify the ICMPv6 type and ICMPv6
code classifiers, no additional bits are added.
TC field 8 –
[ User packet class ] | [ traffic class ] | [ local ] 8 When you specify one or more of the user
packet class, traffic class, and local classifiers, 8
bits are added to the total classifier entry size.
