Table 110: J-Web Ping MPLS Field Summary (continued)
Your ActionFunctionField
Type the source IP address—a valid address
configured on a Services Router interface.
Specifies the source address of the ping request
packet.
Source Address
From the list, select the number of ping requests to
send. The default is 5 requests.
Specifies the number of ping requests to send.Count
Select the check box to display detailed output.Requests the display of extensive rather than brief
ping output.
Detailed Output
Ping LDP-signaled LSP
Type the forwarding equivalence class (FEC) prefix
and length of the LSP to ping.
Identifies the LSP to ping.FEC Prefix
Type the source IP address—a valid address
configured on a Services Router interface.
Specifies the source address of the ping request
packet.
Source Address
From the list, select the number of ping requests to
send. The default is 5 requests.
Specifies the number of ping requests to send.Count
Select the check box to display detailed output.Requests the display of extensive rather than brief
ping output.
Detailed Output
Ping LSP to Layer 3 VPN prefix
Type the name of the VPN to ping.Identifies the Layer 3 VPN to ping.Layer 3 VPN
Name
From the list, select the number of ping requests to
send. The default is 5 requests.
Specifies the number of ping requests to send.Count
Select the check box to display detailed output.Requests the display of extensive rather than brief
ping output.
Detailed Output
Type the IP address prefix and length of the VPN to
ping.
Identifies the IP address prefix and length of the
Layer 3 VPN to ping.
VPN Prefix
Type the source IP address—a valid address
configured on a Services Router interface.
Specifies the source address of the ping request
packet.
Source Address
Locate LSP using interface name
From the list, select the Services Router interface
on which ping requests are sent. If you select any,
the ping requests are sent on all interfaces.
Specifies the interface on which the ping requests
are sent.
(See the interface naming conventions in the J-series
Services Router Basic LAN and WAN Access
Configuration Guide.)
Interface
Type the source IP address—a valid address
configured on a Services Router interface.
Specifies the source address of the ping request
packet.
Source Address
From the list, select the number of ping requests to
send. The default is 5 requests.
Specifies the number of ping requests to send.Count
Select the check box to display detailed output.Requests the display of extensive rather than brief
ping output.
Detailed Output
220 ■ Checking MPLS Connections from the J-Web Interface
