Networking at Layer 2: Logical Interface Types
Two main types of interfaces are used in Layer 2 configurations:
•
Layer 2 logical interface—This type of interface uses the VLAN-ID as a virtual circuit
identifier and the scope of the VLAN-ID is local to the interface port. This type of
interface is often used in service-provider-centric applications.
•
Access or trunk interface—This type of interface uses a VLAN-ID with global significance.
The access or trunk interface is implicitly associated with bridge domains based on
VLAN membership. Access or trunk interfaces are typically used in enterprise-centric
applications.
NOTE: The difference between access interfaces and trunk interfaces is
that access interfaces can be part of one VLAN only and the interface is
normally attached to an end-user device (packets are implicitly associated
with the configured VLAN). In contrast, trunk interfaces multiplex traffic
from multiple VLANs and usually interconnect switches.
