CH-X400/CH-X450
1-16
Mounting the top plate
1. Mount the upper rod on the lifter side (j) and set it on the rear
of the top plate, then mount the other end of the upper rod to
(k).
2. Check that the five points (l, m, n, o and p) are correctly
positioned.
When mounting section (q), set it so that section (D) of the
lifter unit is pinched by the bending section of the top plate.
3. Secure the top plate with six fixing screws (19).
Fig. 39
Fig. 40
Fig. 41
Fig. 42
l
mn
q
p
Upper rod
(D)
Lifter unit
Section "p"
Expanded view of mounting "q"
