CH-X400/CH-X450
3-3
Item Parts number Parts name Area
Parts list (General assembly)
Q'ty Description
Block No.
1 --------------- CD CHANGER MECHA 1
2 LV41843-001A LASER CAUTION 1
3 LV20065-002B-SK FITTING 1
4 LV40706-003A CAUTION LABEL 1
5 QYSDST2004Z SCREW 1
6 LV10407-004A TOP COVER 1 CH-X450U
LV10407-006A TOP COVER 1 CH-X400E/J
7 VYSH101-031 SPACER 1
8 QYSSST2005M SCREW 2
9 LV10408-004A BOTTOM COVER 1 CH-X450U
LV10408-006A BOTTOM COVER 1 CH-X400E/J
10 LV30632-001A INSULATOR 1
11 LV40530-001A BRACKET 2
12 LV30360-004A-SL DIRECTION KNOB 2
13 LV30451-002A DAMPER 4
14 LV40345-003A DAMPER SP
R
1
15 LV40346-003A DAMPER SP
L
1
16 QYSDST2604M SCREW 4 TOP+BOTTOM
17 QYSSST2605M SCREW 6
18 QYSDST2005Z SCREW 2 PWB+TOP
19 QYSDST2606Z SCREW 1 8P+TOP
20 LV20923-004B F.PANEL ASS'Y 1 CH-X400E
LV20923-001B F.PANEL ASS'Y 1 CH-X400J
LV20923-002B F.PANEL ASS'Y 1 CH-X450U
21 LV30786-003A-SL HOLD BRACKET 1
22 QYSDSF2005Z SCREW 2 DOOR-3+HOLD BKT
23 LV32473-002A NAME PLATE 1 CH-X400E
LV32474-003A NAME PLATE 1 CH-X400J
LV32475-003A NAME PLATE 1 CH-X450U
24 VYSS2R2-028 SPACER 1
25 LV40762-001A CAUTION LABEL 1
26 LV40487-003A CAUTION LABEL 1
27 LV40528-005A LABEL 1 CH-X400E/J
LV40528-006A LABEL 1 CH-X450U
28 E70891-001 CLASS 1 LABEL 1
29 LV40847-001A SPACER
H
1
30 VYSA1R4-056 SPACER 1
