- 12 -
The model CL-S500 is intended for use in an electromagnetic environment in which radiated
RF disturbances are controlled. The customer or the user of the model CL-S500 can help
prevent electromagnetic interference by maintaining a minimum distance between portable
and mobile RF communications equipment (transmitters) and the model CL-S500 as
recommended below, according to the maximum output power of the communications
equipment.
Rated maximum
output power of
transmitter
W
Separation distance according to frequency of transmitter
m
150 kHz to 80 MHz
d
= 1.2
80 MHz to 800 MHz
d
= 1.2
800 MHz to 2.7 GHz
d
= 2.3
0.01 0.12 0.12 0.23
0.1 0.38 0.38 0.73
1 1.2 1.2 2.3
10 3.8 3.8 7.3
100 12 12 23
For transmitters rated at a maximum output power not listed above, the recommended
separation distance
d
in meters (m) can be estimated using the equation applicable to the
frequency of the transmitter, where
P
is the maximum output power rating of the transmitter
in watts (W) according to the transmitter manufacturer.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range
applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is
aected by absorption and reection from structures, objects and people.
NOTE 3 The screen of EUT ickers during testing, but it is self-recoverable after test.
NOTE 4 The EUT was stopped operating during the test, but it is self-recoverable after test.
Cables used for the test Length
AC power cord 2.0 m
DisplayPort cable
1.8 m
DVI cable
3.0 m
USB cable
3.0 m
