Getting Started
Controls and Features
 Rear Side/Top Surface
Exhaust Vent
To adjust the size of the image
(pP25)
To adjust the focus
(pP25)
Lamp Cover (pP42)
To connect the power cord (pP24)
Remote Sensor (pP17)
 Front Side/Left Side
Remote Sensor
(pP17)
Air inlets
Lens Cap
z This unit comes with buffer material that cushions the lens. Remove the buffer
material before use.
z Do not throw away the buffer material, retain for future use. (pP50)
DLA-HD1D_EN.book Page 14 Tuesday, January 30, 2007 2:54 PM

JVC DLA-HD1 Specifications

General

Projection distance	3.0/6.1 m
Projection technology	DLP
Contrast ratio (typical)	-
Digital zoom	2 x
Focal length range	21.3 - 42.6 mm
Lamp type	UHP
Lamp power	200 W
Light source type	Lamp
RS-232 ports	1
Dimensions (WxDxH)	455 x 172.5 x 418.5 mm
Connectivity technology	Wired
Full HD	Yes
Serial interface type	RS-232
Power consumption (standby)	2.7 W
Market positioning	Home cinema

Weight and Dimensions

Weight	11600 g
