Specifications
Product Name D-ILA Projector
Model Name DLA-NX9B, DLA-N7B, DLA-N5B, DLA-N5W *1
Display Panel/Size D-ILA device *2, 3
0.69” 4K D-ILA (4096 x 2160 pixels) x 3
Projection Lens 2.0 x power zoom lens, motorized zoom and focus
Light-source Lamp 265 W ultra-high pressure mercury lamp [product no.: PK-L2618U
Average lifespan: 4500 hours (“Low” mode)
Screen Size Approx. 60” to 280” (Aspect ratio of 16:9) k
Approx. 60” to 200” (Aspect ratio of 16:9) u q
Brightness 2200 lm k, 1900 lm u, 1800 lm q
Projection Distance Refer to P. 79.
Input Compatibility Signal Refer to P. 81.
Display Resolution 8192 x 4320 pixels k *4, 4096 x 2160 pixels u q
Input Terminal HDMI Input Dual, HDMI 19-pin x 2 (HDCP 2.2-compatible) *5
Output Terminal Trigger Terminal Single, Ø 3.5 mm DC Power Jack (E)
DC OUT 12 V, 0.1 A
3D synchro Dedicated terminal for 3D Synchro Emitter (single, mini-DIN 3-pin)
Control Terminal RS-232C Terminal Single, D-sub 9-pin (male) (external control)
LAN Terminal Single, RJ-45 plug, 10BASE-T/100BASE-TX
Service Terminal SERVICE Single (USB Type A) *6
Power Requirements AC 100 V to 240 V, 50 Hz/60 Hz
Power Consumption 400 W (during normal standby: 1.5 W *7, during Eco Mode standby:
0.3 W *8)
Operation Environment Temperature: 5°C to 35°C; humidity: 20% to 80%; storage
temperature: -10°C to 60
°C
Installation Height Below 5,000 ft (1,524 m)
Dimensions (Width x Height x Depth) 500 mm x 234 mm x 518 mm (including feet) k
500 mm x 234 mm x 495 mm (including feet) u q
Mass 21.8 kg k, 19.8 kg u, 19.6 kg q
Accessories Refer to P. 9.
*1 “W” indicates that the main unit is white in color. “B” indicates that the main unit is black in color.
*2
D-ILA is the abbreviation for Direct Drive Image Light Amplifier.
*3 D-ILA devices are manufactured using extremely high-precision technology with a pixel effectiveness of 99.99%.
Only 0.01% or less of the pixels are either missing or would remain permanently lit.
*4 During 3D playback, the display resolution is 4096 x 2160 pixels.
*5 HDCP is the abbreviation for High-bandwidth Digital Content Protection system. The image of the HDMI input
terminal may not be displayed in some cases due to changes in the HDCP specifications.
*6 Exclusively for firmware update.
*7 The power consumption of this product during networked standby when all wired network ports are connected
is 1.5 W.
*8 “During standby” refers to Eco Mode standby (P. 61).
0
Design and specifications are subject to change without prior notice.
0
