Getting Started
Controls and Features
 Rear Side/Top Surface
Exhaust Vent
To adjust the size of the image
(pP21)
To adjust the focus
(pP21)
Lamp Cover (pP38)
To connect the power cord (pP20)
Remote Sensor (pP13)
 Front Side/Left Side
Remote Sensor
(pP13)
Air inlets
Lens Cap
z This unit comes with buffer material that cushions the lens. Remove the buffer
material before use.
z Do not throw away the buffer material, retain for future use. (pP46)
