JVC DR-M10SEF - Electrical Parts List; Regulator Board

(No.XA020)3-5
Electrical parts list
Regulator board
Block No. [0][1]
 Symbol No. Part No. Part Name Description Local
PW1 LPA10235-03C REGULATOR BOARD ASSY
IC5101 STR-G6653-F9 IC
IC5301 UTCTL431-T IC
IC5301 or MM1431AT-T IC
IC5301 or L5431-T IC
IC5301 or TL431/A/-T IC
IC5302 PQ5EV3 IC
IC5304 MM1565AF-X IC 5.0V
IC5305 MM1662GH-X IC
IC5306 MM1563EF-X IC 3.4V
Q5301 DTA114EKA-X DIGI TRANSISTOR
Q5301 or UN2111-X TRANSISTOR
Q5301 or RT1P141C-X DIGI TRANSISTOR
Q5302 DTC114EKA-X TRANSISTOR
Q5302 or UN2211-X TRANSISTOR
Q5302 or RT1N141C-X DIGI TRANSISTOR
Q5303 DTA114EKA-X DIGI TRANSISTOR
Q5303 or UN2111-X TRANSISTOR
Q5303 or RT1P141C-X DIGI TRANSISTOR
Q5304 DTC114EKA-X TRANSISTOR
Q5304 or UN2211-X TRANSISTOR
Q5304 or RT1N141C-X DIGI TRANSISTOR
Q5305 2SD2144S/UV/-T TRANSISTOR
Q5305 or 2SC3576-JVC-T TRANSISTOR
Q5308 2SD1858/QR/-T TRANSISTOR
Q5310 2SD2144S/UV/-T TRANSISTOR
Q5310 or 2SC3576-JVC-T TRANSISTOR
Q5313 2SA1585S/QR/-T TRANSISTOR
Q5314 DTC114EKA-X TRANSISTOR
Q5314 or UN2211-X TRANSISTOR
Q5314 or RT1N141C-X DIGI TRANSISTOR
Q5315 2SA1585S/QR/-T TRANSISTOR
Q5316 2SA1585S/QR/-T TRANSISTOR
Q5317 DTC114EKA-X TRANSISTOR
Q5317 or UN2211-X TRANSISTOR
Q5317 or RT1N141C-X DIGI TRANSISTOR
 D5001 D3SBA60 DIODE
D5001 or GBJ4J BRIDGE DIODE
D5101 10ERB40-T2 FR DIODE
D5101 or AU01-T2 SI DIODE
D5101 or ERA18-04-T2 FR DIODE
D5101 or 1SR153-400-T2 FR DIODE
D5101 or 1F4G-T2 FR DIODE
D5102 10ERB40-T2 FR DIODE
D5102 or AU01-T2 SI DIODE
D5102 or ERA18-04-T2 FR DIODE
D5102 or 1SR153-400-T2 FR DIODE
D5102 or 1F4G-T2 FR DIODE
D5103 1F4G-T2 FR DIODE
D5103 or 10ERB40-T2 FR DIODE
D5103 or ERA18-02-T2 FR DIODE
D5103 or AU01Z-T2 FR DIODE
D5103 or 1SR153-400-T2 FR DIODE
D5104 1SS133-T2 DIODE
D5104 or 1SS270A-T2 SI DIODE
D5105 10ERB40-T2 FR DIODE
D5105 or ERA18-02-T2 FR DIODE
D5105 or AU01Z-T2 FR DIODE
D5105 or 1SR153-400-T2 FR DIODE
D5105 or 1F4G-T2 FR DIODE
D5106 10ERB40-T2 FR DIODE
D5106 or ERA18-02-T2 FR DIODE
D5106 or AU01Z-T2 FR DIODE
D5106 or 1SR153-400-T2 FR DIODE
D5106 or 1F4G-T2 FR DIODE
D5201 10ERB40-T2 FR DIODE
D5201 or ERA18-02-T2 FR DIODE
D5202 RK34-LFB2 SB DIODE
D5203 RK34-LFB2 SB DIODE
D5204 RK34-LFB2 SB DIODE
D5205 RL2Z-LFB2 FRD
D5206 1F4G-T2 FR DIODE
D5206 or 10ERB40-T2 FR DIODE
D5206 or ERA18-02-T2 FR DIODE
D5206 or AU01Z-T2 FR DIODE
D5206 or 1SR153-400-T2 FR DIODE
D5207 1F4G-T2 FR DIODE
D5207 or 10ERB40-T2 FR DIODE
D5207 or ERA18-02-T2 FR DIODE
D5207 or AU01Z-T2 FR DIODE
D5207 or 1SR153-400-T2 FR DIODE
D5208 RK34-LFB2 SB DIODE
D5209 RK34-LFB2 SB DIODE
D5210 RK34-LFB2 SB DIODE
D5211 1F4G-T2 FR DIODE
D5211 or 10ERB40-T2 FR DIODE
D5211 or ERA18-02-T2 FR DIODE
D5211 or AU01Z-T2 FR DIODE
D5211 or 1SR153-400-T2 FR DIODE
D5301 MTZJ15A-T2 Z DIODE
D5301 or RD15ES/B1/-T2 Z DIODE
D5302 MTZJ12B-T2 Z DIODE
D5302 or RD12ES/B2/-T2 Z DIODE
D5303 MTZJ11C-T2 Z DIODE
D5303 or RD11ES/B3/-T2 Z DIODE
D5304 MTZJ5.6C-T2 Z DIODE
D5304 or RD5.6ES/B3/-T2 Z DIODE
D5305 RL2Z-LFB2 FRD
D5306 1SS133-T2 DIODE
D5306 or 1SS270A-T2 SI DIODE
D5307 MTZJ27C-T2 Z DIODE
D5307 or RD27ES/B3/-T2 Z DIODE
D5308 RK34-LFB2 SB DIODE
D5309 RK34-LFB2 SB DIODE
D5310 RK34-LFB2 SB DIODE
D5311 1S4-T2 SB DIODE
D5311 or AW04-T2 SB DIODE
D5311 or SBO40-T2 SB DIODE
D5311 or 11EQS04-T2 SB DIODE
D5314 1SS133-T2 DIODE
D5314 or 1SS270A-T2 SI DIODE
D5315 1A3G-T2 SI DIODE
D5315 or 10EDB20-T2 SI DIODE
D5315 or ERA15-02-T2 SI DIODE
D5318 1A3G-T2 SI DIODE
D5318 or 10EDB20-T2 SI DIODE
D5318 or ERA15-02-T2 SI DIODE
 PC5101 PC123Y22FZ PHOTO COUPLER
 C5001 QFZ9073-683 MM CAPACITOR 0.068uF AC250V M
 C5002 QFZ9073-223 MM CAPACITOR 0.022uF AC250V M
C5003 QEZ0374-826 E CAPACITOR 82uF 400V M
 C5004 QCZ9079-222 C CAPACITOR 2200pF AC250V M
C5101 QCZ0339-101Z C CAPACITOR 100pF 1kV K
C5102 QCZ0349-472Z C CAPACITOR 4700pF 1kV K
C5103 QEMU1VM-276Z E CAPACITOR 27uF 35V M
C5104 QCZ0136-471Z C CAPACITOR 470pF 1kV K
C5105 QFLC1HJ-471Z M CAPACITOR 470pF 50V J
C5106 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C5107 NCB31HK-221X C CAPACITOR 220pF 50V K
C5201 QEMX0JM-227Z E CAPACITOR 220uF 6.3V M
C5202 QEMT0JM-128 E CAPACITOR 1200uF 6.3V M
C5203 QEMT1AM-228 E CAPACITOR 2200uF 10V M
C5204 QEMT1CM-228 E CAPACITOR 2200uF 16V M
C5205 QETN2AM-475Z E CAPACITOR 4.7uF 100V M
C5206 QEMU1HM-186Z E CAPACITOR 18uF 50V M
C5207 QEMT1AM-228 E CAPACITOR 2200uF 10V M
C5208 QEMT1AM-228 E CAPACITOR 2200uF 10V M
C5209 QEMT1CM-687 E CAPACITOR 680uF 16V M
C5301 QFVF1HJ-154Z MF CAPACITOR 0.15uF 50V J
C5302 QFLC1HJ-333Z M CAPACITOR 0.033uF 50V J
C5303 NCF31AZ-105X C CAPACITOR 1uF 10V Z
 Symbol No. Part No. Part Name Description Local
