JVC DR-M10SEF - Digital Board

3-6(No.XA020)
Digital board
Block No. [0][2]
C5304 QETN1AM-107Z E CAPACITOR 100uF 10V M
C5305 QETN1AM-107Z E CAPACITOR 100uF 10V M
C5306 QETN1CM-107Z E CAPACITOR 100uF 16V M
C5307 QETN1AM-107Z E CAPACITOR 100uF 10V M
C5308 QETN1CM-107Z E CAPACITOR 100uF 16V M
C5309 QETN1CM-107Z E CAPACITOR 100uF 16V M
C5310 QETN1HM-226Z E CAPACITOR 22uF 50V M
C5311 QETN1HM-226Z E CAPACITOR 22uF 50V M
C5312 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C5316 QETN1AM-107Z E CAPACITOR 100uF 10V M
C5317 QETN1AM-107Z E CAPACITOR 100uF 10V M
C5318 NCB31HK-471X C CAPACITOR 470pF 50V K
C5319 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C5320 NCB31HK-471X C CAPACITOR 470pF 50V K
C5321 QETN1HM-226Z E CAPACITOR 22uF 50V M
C5322 QETN1CM-107Z E CAPACITOR 100uF 16V M
C5323 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C5326 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C5327 NCB31HK-471X C CAPACITOR 470pF 50V K
R5101 QRG02GJ-683 OMF RESISTOR 68k
Ω 2W J
R5102 NRSA63J-122X MG RESISTOR 1.2k
Ω 1/16W J
R5103 QRG02GJ-683 OMF RESISTOR 68k Ω 2W J
R5104 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R5105 QRE141J-680Y C RESISTOR 68 Ω 1/4W J
R5106 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J
R5107 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R5108 QRT01DJ-R33X MF RESISTOR 0.33 Ω 1W J
R5301 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R5302 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R5303 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R5304 NRSA63D-682X MG RESISTOR 6.8k Ω 1/16W D
R5305 NRSA63D-203X MG RESISTOR 20k Ω 1/16W D
R5306 NRSA63D-392X MG RESISTOR 3.9k Ω 1/16W D
R5310 QRE141J-8R2Y C RESISTOR 8.2 Ω 1/4W J
 R5314 QRZ9051-470X FUSI RESISTOR 47 Ω 1/4W J
R5317 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R5318 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R5319 NRSA63D-302X MG RESISTOR 3k Ω 1/16W D
R5320 NRSA63D-472X MG RESISTOR 4.7k Ω 1/16W D
R5321 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R5323 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R5324 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R5327 QRE141J-681Y C RESISTOR 680 Ω 1/4W J
R5328 QRE141J-821Y C RESISTOR 820 Ω 1/4W J
R5329 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5330 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R5331 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R5332 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R5333 QRE123J-101X C RESISTOR 100
Ω 1/2W J
R5334 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R5335 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R5336 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R5337 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
L5201 PELN1184 CHOKE COIL
L5202 PELN1184 CHOKE COIL
L5203 PELN1184 CHOKE COIL
L5204 PELN1184 CHOKE COIL
L5205 PELN1184 CHOKE COIL
L5206 PELN1184 CHOKE COIL
 T5001 QQS0263-001 SW TRANSF
B5504 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
B5507 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
 CN5001 QGA7901C3-02 CONNECTOR W-B (1-2)
CN5301 QGF1207C1-19 CONNECTOR FFC/FPC (1-19)
CN5302 QGB1231L1-09 CONNECTOR B-B (1-9)
CN5303 QGA2501C1-04 CONNECTOR W-B (1-4)
CN5305 QGA2001C1-02 CONNECTOR W-B (1-2)
 CP5301 QMFZ050-1R5X-E FUSE 1.5A 125V
 F5001 QMF51E2-1R6-J1 FUSE 1.6A AC250V
FC5001 QNG0020-001Z FUSE CLIP
FC5002 QNG0020-001Z FUSE CLIP
HS1 PEME0889-01-01 HEAT SINK
K5102 QQR0678-001Z FERRITE BEADS
 LF5002 QQR1031-001 LINE FILTER
OT1 QYTDST3008Z TAP SCREW M3 x 8mm IC5101
 Symbol No. Part No. Part Name Description Local
OT2 LP31414-001A PROTECT SHEET
ST1 PU59391 STYLE PIN
 Symbol No. Part No. Part Name Description Local
PW1 LPA10236-03C DIGITAL BOARD ASSY
IC1001 JCP8059 IC
IC1002 HY57V161610DTC7 IC
IC1002 or K4S161622H-TC80 IC
IC1002 or MT48LC1M16A1TG8 IC
IC1002 or HY57V161610DTC8 IC
IC1002 or MT48LC1M16TG-7S IC
IC1201
MBPL65LMDRM10EU IC
IC1202
SN74LVC373APW-X IC(DIGITAL)
IC1203 SN74LVC373APW-X IC(DIGITAL)
IC1401 DMN8652-B0 IC(DIGITAL)
IC1404 SN74HCT08APW-X IC
IC1405 SN74LV08APW-X IC
IC1601 HY5DU561622CT-J IC
IC1602 HY5DU561622CT-J IC
IC1701 PQ015YZ01Z-X IC
IC1801 TSB41AB2PAP IC
Q1002 2SA1037AK/QR/-X TRANSISTOR
Q1002 or 2SA1530A/QR/-X SI TRANSISTOR
Q1002 or 2SB709A/QR/-X TRANSISTOR
Q1003 2SA1037AK/QR/-X TRANSISTOR
Q1003 or 2SA1530A/QR/-X SI TRANSISTOR
Q1003 or 2SB709A/QR/-X TRANSISTOR
Q1004 2SA1037AK/QR/-X TRANSISTOR
Q1004 or 2SA1530A/QR/-X SI TRANSISTOR
Q1004 or 2SB709A/QR/-X TRANSISTOR
Q1005 2SA1037AK/QR/-X TRANSISTOR
Q1005 or 2SA1530A/QR/-X SI TRANSISTOR
Q1005 or 2SB709A/QR/-X TRANSISTOR
Q1006 2SA1037AK/QR/-X TRANSISTOR
Q1006 or 2SA1530A/QR/-X SI TRANSISTOR
Q1006 or 2SB709A/QR/-X TRANSISTOR
Q1007 2SA1037AK/QR/-X TRANSISTOR
Q1007 or 2SA1530A/QR/-X SI TRANSISTOR
Q1007 or 2SB709A/QR/-X TRANSISTOR
Q1008 UMZ1N-W PAIR TRANSISTOR
Q1008 or BC847PN-X PAIR TRANSISTOR
Q1008 or BC846PN-X PAIR TRANSISTOR
Q1009
2SC2412K/QRS/-X TRANSISTOR
Q1009 or 2SC3928A/QRS/-X TRANSISTOR
Q1009 or 2SD601A/QRS/-X TRANSISTOR
Q1010 2SC2412K/QRS/-X TRANSISTOR
Q1010 or 2SC3928A/QRS/-X TRANSISTOR
Q1010 or 2SD601A/QRS/-X TRANSISTOR
Q1011
2SC2412K/QRS/-X TRANSISTOR
Q1011 or
2SC3928A/QRS/-X TRANSISTOR
Q1011 or 2SD601A/QRS/-X TRANSISTOR
D1001 1SS355-X SI DIODE
D1001 or MA111-X SI DIODE
D1002 1SS355-X SI DIODE
D1002 or MA111-X SI DIODE
D1401 1SS355-X SI DIODE
D1401 or MA111-X SI DIODE
D1402 1SS355-X SI DIODE
D1402 or MA111-X SI DIODE
D1403 1SS355-X SI DIODE
D1403 or MA111-X SI DIODE
C1001 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M
C1002 NBE20JM-106X
TA E CAPACITOR 10uF 6.3V M
C1003 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1004 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C1005 NCB31CK-104X C CAPACITOR 0.1uF 16V K
 Symbol No. Part No. Part Name Description Local
