(No.XA020)3-15
Operation board
Block No. [2][7]
Swich display board
Block No. [2][8]
W23 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W24 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W25 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W26 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W27 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W28 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W29 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W30 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W31 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W32 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W33 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W34 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W35 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W36 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W37 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W38 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W39 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W40 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W41 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W42 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W43 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W44 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W45 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W46 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W47 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W48 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W49 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W50 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W51 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W52 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W53 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W54 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W55 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W56 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W57 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
X3001 QAX0444-001 CRYSTAL 32.768kHz
M10SEF,M10SEK
X3001 QAX0445-001 CRYSTAL 32.768kHz
M10BE,M10SE,M10SER
X3002 QAX0527-001 CRYSTAL 10.000000MHz
X4001 QAX0576-001 CRYSTAL 4.433619MHz
X6701 QAX0773-001Z CRYSTAL 18.432000MHz
Symbol No.
Part No. Part Name Description Local
PW1 LPA10239-01A3 OPERATION BOARD ASSY
Q7103 DTA114ESA-T DIGI TRANSISTOR
D7112 1SS133-T2 DIODE
D7112 or 1SS270A-T2 SI DIODE
D7113 1SS133-T2 DIODE
D7113 or 1SS270A-T2 SI DIODE
D7114 1SS133-T2 DIODE
D7114 or 1SS270A-T2 SI DIODE
D7115 1SS133-T2 DIODE
D7115 or 1SS270A-T2 SI DIODE
D7123 SLR-343MC-T LED
C7150 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
C7151 NCB31HK-102X C CAPACITOR 1000pF 50V K
C7153 NCB31HK-102X C CAPACITOR 1000pF 50V K
R7106 QRE141J-331Y C RESISTOR 330
Ω
1/4W J
R7151 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R7152 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R7153 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R7154 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7155 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R7156 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
B7108 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
CN7101 QGF1208F1-09 CONNECTOR FFC/FPC (1-9)
Symbol No.
Part No. Part Name Description Local
CN7102 QGF1208F1-11 CONNECTOR FFC/FPC (1-11)
J7001 QND0084-001 S JACK S-VIDEO IN
J7002 QNN0364-002 PIN JACK A/V IN
S7113 QSW0381-001Z TACT SWITCH REC
S7114 QSW0381-001Z TACT SWITCH REC MODE
S7115 QSW0381-001Z TACT SWITCH PAUSE
S7132 QSW0381-001Z TACT SWITCH OPEN/CLOSE
S7133 QSW0381-001Z TACT SWITCH SAT
S7134 QSW0381-001Z TACT SWITCH STOP
S7135 QSW0381-001Z TACT SWITCH PLAY
W7151 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W7152 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W7153 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
W7154 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
Symbol No.
Part No. Part Name Description Local
PW1 LPA10239-01A2 SWICH DISPLAY BOARD ASSY
IC7001
UPD16315GB-3BS
IC
IC7001 or PT6315 IC
IC7002 GP1UM281XK IR DETECT UNIT 38kHz
IC7002 or PNA4652M00XB IR DETECT UNIT
Q7001 2SC1740S/QRS/-T TRANSISTOR
Q7001 or 2SC3199/YG/-T TRANSISTOR
Q7001 or KTC3199/YG/-T TRANSISTOR
D7001 1SS133-T2 DIODE
D7001 or 1SS270A-T2 SI DIODE
D7021 RD9.1ES/B2/-T2 Z DIODE
D7021 or MTZJ9.1B-T2 Z DIODE
D7042 1SS133-T2 DIODE
D7042 or 1SS270A-T2 SI DIODE
D7043 SDPB3DC0 LED
C7001 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C7002 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C7003 QEKJ1HM-106Z E CAPACITOR 10uF 50V M
C7006 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C7007 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C7008 QEKJ0JM-227Z E CAPACITOR 220uF 6.3V M
C7010 QCFB1HZ-473Y C CAPACITOR 0.047uF 50V Z
C7011 QCFB1HZ-473Y C CAPACITOR 0.047uF 50V Z
C7056 QEKJ1EM-106Z E CAPACITOR 10uF 25V M
R7001 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7002 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7003 NRSA63J-823X MG RESISTOR 82k
Ω
1/16W J
R7005 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R7006 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R7007 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7009 QRE141J-103Y C RESISTOR 10k
Ω
1/4W J
R7010 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R7013 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R7014 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R7015 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R7044 QRE141J-392Y C RESISTOR 3.9k
Ω
1/4W J
R7045 QRE141J-270Y C RESISTOR 27
Ω
1/4W J
R7047 QRE141J-182Y C RESISTOR 1.8k
Ω
1/4W J
CN7001 QGF1207C1-18 CONNECTOR FFC/FPC (1-18)
DI7001 QLF0121-001 FL TUBE
HD1 PQ34949-1-1 FDP HOLDER(L)
HD2 LP21255-001A FL HOLDER(R)
S7001 QSW0381-001Z TACT SWITCH OPERATION
Symbol No.
Part No. Part Name Description Local
