JVC DR-M10SEF User Manual

(No.XA020)1-11
5.1.1 Setting JIG mode
To display SYSTEM INFO or to upgrade firmware, the main body needs to be set to JIG mode.
(1) Turn the main body ON.
(2) Press the buttons of the remote control unit attached to product in the following order : "SET UP" → "2" → "8" → "ENTER"
(3) When a colon ":" between "hour" and "minute" of a clock in FL indicator blink, it means that the main body has been set to JIG
mode properly.
(4) Turn the main body OFF, and then turn it ON again.
*Once the main body is set to JIG mode, the JIG mode cannot be cancelled even if the power cord is pulled out from the wall
socket.
5.1.2 Canceling JIG mode
(1) Transmit "43-9D" to the main body by using JIG remote control unit.
(2) A colon ":" between "hour" and "minute" of a clock in FL indicator light.
(3) Turn the main body OFF, and then turn it ON again.
NOTE:
After repair work, be sure to cancel JIG mode. Before returning product to a user, confirm that a colon ":" between "hour" and
"minute" of a clock in FL indicator light.
Not in JIG mode In JIG mode
[ Example ]
15 : 07
15 07
A colon blinks.
CABLE/DBS
DVDTV
DVD
CH
TIMER REC LINK PROG/CHECK VCR Plus+
NEXTPREVIOUS
PAUSEREC
REC MODE LIVE CHECK
SET UP DISPLAY ON SCREEN
OPEN/
CLOSE
AUDIO SUBTITLE ANGLE
PROGRESSIVE
SCAN
SLOWSLOW PLAY/SELECT
STOP/
CLEAR
NAVIGATIONTOP MENU
RETURN
ENTER
MENU
TV/CBL/DBS
STANDBY/ON
TV
MUTING
TV/
VIDEO
TV VOLUME
ABC
JKLGHI MNO
TUVPQRS WXYZ
AUXCANCEL MEMO/MARK
DBS
DEF
STANDBY/ON
S-VIDEO VIDEO
L(MONO) - AUDI O - R
DV DV IN
F1
REC MODE
PULL - OPEN
SAT
(2)b
(2)c
(2)d
(2)a
(3)
(1),(4)
"(2) a-d" shows the order of pressing the buttons.
15:07

JVC DR-M10SEF Specifications

General

Brand	JVC
Model	DR-M10SEF
Category	DVR
Language	English
