JVC DR-M10SEF - Page 44

3-10(No.XA020)
Main board
Block No. [0][3]
K1008 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K1009 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K1010 NQR0129-002X FERRITE BEADS
K1011 NQR0129-002X FERRITE BEADS
K1012 NQR0129-002X FERRITE BEADS
K1013 NQR0129-002X FERRITE BEADS
K1014 NQR0129-002X FERRITE BEADS
K1015 NQR0129-002X FERRITE BEADS
K1016 NQR0129-002X FERRITE BEADS
K1017 NQR0129-002X FERRITE BEADS
K1018 NQR0129-002X FERRITE BEADS
K1019 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K1020 NQR0129-002X FERRITE BEADS
K1201 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
K1401 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K1402 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K1403 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K1404 NQR0339-001X FERRITE BEADS
K1406 NQR0339-001X FERRITE BEADS
K1407 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K1408 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K1701 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K1702 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K1801 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K2201 NQR0129-002X FERRITE BEADS
K2202 NQR0129-002X FERRITE BEADS
K2203 NQR0129-002X FERRITE BEADS
K2204 NQR0129-002X FERRITE BEADS
K2205 NQR0129-002X FERRITE BEADS
K2206 NQR0129-002X FERRITE BEADS
K2207 NQR0129-002X FERRITE BEADS
K2208 NQR0129-002X FERRITE BEADS
K2209 NQR0129-002X FERRITE BEADS
K2210 NQR0129-002X FERRITE BEADS
K2211 NQR0129-002X FERRITE BEADS
K2212 NQR0129-002X FERRITE BEADS
K2213 NQR0129-002X FERRITE BEADS
K2214 NQR0129-002X FERRITE BEADS
K2215 NQR0129-002X FERRITE BEADS
K2216 NQR0129-002X FERRITE BEADS
K2217 NQR0129-002X FERRITE BEADS
K2218 NQR0129-002X FERRITE BEADS
K2219 NQR0129-002X FERRITE BEADS
K2220 NQR0129-002X FERRITE BEADS
K2221 NQR0129-002X FERRITE BEADS
LC1401 NQR0415-002X EMI FILTER 1uF 16V Z
LC1402 NQR0415-002X EMI FILTER 1uF 16V Z
LC1403 NQR0415-002X EMI FILTER 1uF 16V Z
OT1 LC41656-001A COOLING SHEET
SD1 LP21258-001A SHIELD CASE
X1401 NAX0580-001X CXO 27.0000MHz
X1801 NAX0666-001X CRYSTAL 24.576000MHz
 Symbol No. Part No. Part Name Description Local
PW1 LPA10239-01C1 MAIN BOARD ASSY M10SEF
PW1 LPA10239-02C1 MAIN BOARD ASSY M10SEK
PW1 LPA10239-03C1 MAIN BOARD ASSY
M10BE,M10SE,M10SER
IC3001 HD6432194SXD77F IC(MCU)
IC3001 or HD64F2194FD77 IC(MCU)
IC3001 or HD64F2194CFD77 IC(MCU)
IC3002 IC-PST3427U-X IC
IC3004 LPN0867-003B-33 IC(EEPROM) M10SEF
IC3004 LPN0867-001B-32 IC(EEPROM) M10SEK
IC3004 LPN0867-002A-31 IC(EEPROM) M10BE,M10SE,M10SER
IC4001 JCP8038-I IC
IC4001 or JCP8038 IC
IC4201 LC74793 IC
IC4301 LA7357M-W IC M10SEF
IC4304 74HC4538D-X IC M10SEF
 Symbol No. Part No. Part Name Description Local
IC6701 MSP3417GQGB8V3X IC
IC6701 or MSP3417G-X IC
IC7301 MM1623XF-X IC
IC7302 MM1508XN-X IC
IC7303 TC74HC4053AF-X IC
IC7303 or
CD74HC4053NS-X IC
IC7304 MM1501XN-X IC
IC8001 AK5365VQ IC
IC8201 AK4385VT-X IC
IC8201 or AK4381VT-X IC
IC8202 BA15218F-XE IC
IC8301 LA7151M-X IC
IC8302 LA7151M-X IC
IC8303 BA15218F-XE IC
IC8501 SN74LV08APW-X IC
Q3004
2SC2412K/QRS/-X TRANSISTOR
Q3004 or 2SD601A/QRS/-X TRANSISTOR
Q3004 or 2SC3928A/QRS/-X TRANSISTOR
Q3007 UN221E-X TRANSTSTOR
Q3007 or DTC144WKA-X DIGI TRANSISTOR
Q3007 or RT1N44HC-X DIGI TRANSISTOR
Q3009 UN221E-X TRANSTSTOR
Q3009 or DTC144WKA-X DIGI TRANSISTOR
Q3009 or RT1N44HC-X DIGI TRANSISTOR
Q3010 UN221E-X TRANSTSTOR
Q3010 or DTC144WKA-X DIGI TRANSISTOR
Q3010 or RT1N44HC-X DIGI TRANSISTOR
Q3901 UN221E-X TRANSTSTOR
Q3901 or DTC144WKA-X DIGI TRANSISTOR
Q3901 or RT1N44HC-X DIGI TRANSISTOR
Q4001 2SB709A/QR/-X TRANSISTOR
Q4001 or 2SA1037AK/QR/-X TRANSISTOR
Q4001 or 2SA1530A/QR/-X SI TRANSISTOR
Q4003 2SD601A/QRS/-X TRANSISTOR
Q4003 or 2SC2412K/QRS/-X TRANSISTOR
Q4003 or 2SC3928A/QRS/-X TRANSISTOR
Q4006 2SC2412K/QRS/-X TRANSISTOR
Q4006 or 2SC3928A/QRS/-X TRANSISTOR
Q4101 2SD2144S/UV/-T TRANSISTOR
Q4101 or 2SC3576-JVC-T TRANSISTOR
Q4301 2SD601A/QRS/-X TRANSISTOR M10SEF
Q4301 or 2SC2412K/QRS/-X TRANSISTOR M10SEF
Q4301 or 2SC3928A/QRS/-X TRANSISTOR M10SEF
Q4302 2SB709A/QR/-X TRANSISTOR M10SEF
Q4302 or 2SA1037AK/QR/-X TRANSISTOR M10SEF
Q4302 or 2SA1530A/QR/-X SI TRANSISTOR M10SEF
Q4303 2SB709A/QR/-X TRANSISTOR M10SEF
Q4303 or 2SA1037AK/QR/-X TRANSISTOR M10SEF
Q4303 or 2SA1530A/QR/-X SI TRANSISTOR M10SEF
Q6030 2SA1037AK/QR/-X TRANSISTOR
Q6030 or 2SB709A/QR/-X TRANSISTOR
Q6030 or 2SA1530A/QR/-X SI TRANSISTOR
Q6031 UN2211-X TRANSISTOR
Q6031 or DTC114EKA-X TRANSISTOR
Q7201 2SC1317/RS/-T TRANSISTOR
Q7301 2SD601A/QRS/-X TRANSISTOR
Q7301 or 2SC2412K/QRS/-X TRANSISTOR
Q7301 or 2SC3928A/QRS/-X TRANSISTOR
Q7302 2SD601A/QRS/-X TRANSISTOR
Q7302 or 2SC2412K/QRS/-X TRANSISTOR
Q7302 or 2SC3928A/QRS/-X TRANSISTOR
Q7310 2SB709A/QR/-X TRANSISTOR
Q7310 or 2SA1037AK/QR/-X TRANSISTOR
Q7310 or 2SA1530A/QR/-X SI TRANSISTOR
Q7311 2SB709A/QR/-X TRANSISTOR
Q7311 or 2SA1037AK/QR/-X TRANSISTOR
Q7311 or 2SA1530A/QR/-X SI TRANSISTOR
Q7312 UN221E-X TRANSTSTOR
Q7312 or DTC144WKA-X DIGI TRANSISTOR
Q7312 or RT1N44HC-X DIGI TRANSISTOR
Q7313 UN221E-X TRANSTSTOR
Q7313 or DTC144WKA-X DIGI TRANSISTOR
Q7313 or RT1N44HC-X DIGI TRANSISTOR
Q7314 UN221E-X TRANSTSTOR
Q7314 or DTC144WKA-X DIGI TRANSISTOR
Q7314 or RT1N44HC-X DIGI TRANSISTOR
Q7315 DTC114TKA-X TRANSISTOR
 Symbol No. Part No. Part Name Description Local
